Self Service Kiosk DCA-A238S

Self Service Kiosk DCA-A238S

DCA-A238S 23.8 Inch Self Ordering Kiosk

Optimal 23.8-inch Full HD Interactive Display:

The DCA-A238 features a vibrant 23.8-inch Full HD (1920×1080) IPS display, offering crisp visuals and wide viewing angles. This screen size is ideal for detailed information display and comfortable user interaction in various self-service applications.
Equipped with a responsive 10-point PCAP (Projected Capacitive) multi-touch screen, it ensures an intuitive and smooth user experience, vital for engaging customers effectively.

Designed for Versatile Self-Service Applications:

The DCA-A238 is engineered as a robust platform for diverse self-service needs, including self-ordering (QSR, restaurants), self-checkout (retail), information provision, ticketing, and patient check-in (healthcare). Its design facilitates streamlined operations and enhanced customer engagement for your clients.

Full OEM/ODM Customization – Your Brand, Our Manufacturing:

Beyond specifications, we specialize in complete OEM/ODM customization. This includes tailoring the enclosure color, applying your branding (logo), and even modifying aspects of the design to create a unique product that represents your brand and meets your specific market needs.

Products

Windows POS

Android POS

Self Service Kiosk

Touch Screen Monitor

POS Peripherals

Handheld POS Terminal

Description

Model	DCA-A238S
Optional Colors	White
CPU	J1900 ,Core I3 , CORE I5, CORE I7
Memory Support	8GB Optional 4GB, 8GB 16GB DDR4
Hard Driver	SSD 256GB Optional:64GB (default), SSD 128GB, 256GB HDD 500GB, 1T optional
LCD panel Size	23.8 inch optional : 21.5/24/27/32 inch FHD LCD panel
Contrast ratio	1500:1
Visual Angle	89/89/89/89 (Typ.)(CR≥10)
Reaction time	5ms
Panel life	For 50,000 hours
Brightness	300cd/m2
Resolution	1920*1080 2K 16:9
Touch Screen	10 points projected capacitive touch panel
Material	Metal shell+tempered glass
Surface	Spray paint
Antenna	builded in
Install way	wall mount
Height	Adjustable
I/O interface	USB*4
	LAN: RJ45*1
	POWER interface*1
	WIFI
Operating temperature	0 to 50°C
Storage temperature	-10 to 60°C
Warranty	One year
Weight	NET: 13KG Gross :15kg
Carton size	87.519.542.5cm
Operating system	Win 10 opentional: Windows 7/8/10, Ubuntu, Linux
Power adapter	DC:12V-8A AC:110V-220V
Barcode scanner	2D barcode scanner(can read 1d and 2d barcode both) Cmos: 640×480 CMOS 120FPS 1D barcode: Interleaved 2 of 5, ISBN, Code 93, Code 11,UCC/EAN-128 GS1 Databar, Matrix 2 of 5, Industrial 2 of 5,Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar,Standard 2 of 5, MSI-Plessey,GS1 composite code 2D barcode:PDF417, Data Matrix, QR Code Voltage and currenct: 5V 260mA Reading accuracy: 4mil barcode
Pirnter	80MM thermal receipt printer with auto cutter max printing speed 150mm/s 58mm and 80mm paper both ok working life of printing:50KM Paper loading: loading in front Dpi:203PDI
Space for POS machine	Yes
Camera	Optional Pixel: 2 megapixels 1920*1080fhd Output format:YUV/MJPEG.H.264 camera white balance:automatic
Mobile communication module	Optional frequency band:FDD LTE: B1/B3/B8 TDD LTE: B38/B39/B40/B41 TDSCDMA: B34/B39 WCDMA: B1/B8CDMA 1x/EVDO: BC0GSM: 900/1800
Card reader	Optional IC/ID card reader
